Digi Connect IT 16, Console Access Server with 16 Serial Ports

$2,226.05

In Stock
FREE GROUND SHIPPING *

Digi Connect IT 16, Console Access Server with 16 Serial Ports MFG: Digi International
UPC: 663072964900

  • 1.95 GB
  • Optical Fiber, Twisted Pair
  • 2 Total Expansion Slot(s)
  • 2 x Network (RJ-45)
  • 2 x USB
  • 16 x Serial Port
  • PoE Ports
  • 10/100/1000Base-T, 10GBase-X
  • 10 Gigabit Ethernet

* ground shipping normally takes 3-10 business days, depending on destination

Click here to view our Return Policy
Click here to view our full Terms of Sale


Overview

Centrally manage routers, firewalls, servers and other critical IT infrastructure over LTE or enterprise WAN

Reduce downtime, and simplify cabling, deployment, maintenance and change management. The highly redundant design of Connect® IT 16/48 with dual Ethernet, dual SFP+ and dual power (field replaceable) provides a robust and resilient solution for demanding IT infrastructure management applications. Flexible power supply kits offer the ability to deploy the product into hot or cold aisles. Software selectable reversing serial cable pinout allows straight-through connectivity to most IT infrastructure devices.

Digi Remote Manager® (DRM) provides a single pane of glass interface to all devices across the enterprise and around the world, enabling management of complex, hyperscale and edge compute equipment.

Digi CORE™ LTE modems offer dual SIM support across the family of Digi enterprise routers and now Connect IT 16/48 products. These products are managed globally using DRM and enable network backup for mission critical data delivery for remote locations.

Finance, healthcare, global commerce and managed service companies can use the Connect IT 16/48 to help deliver the highest levels of reliability in support of their critical businesses.

FEATURES AND BENEFITS
  • Digi CORE LTE modems support CAT-M, CAT 1, CAT 4 and Cat 6 in multiple regions
  • Power supply kit provides dual replaceable redundant internal power
  • Digi Connect IT 16
    • (16) RJ45 RS-232 (standard/reversed mode selectable)
  • Digi Connect IT 48
    • (48) RJ45 RS-232 (standard/reversed mode selectable)
  • Digi Foundations™ 1-, 3- or 5-year subscription available

Tech Specs

Manufacturer Digi International
Manufacturer Part Number IT16-1002
Manufacturer Website Address http://www.digi.com
Brand Name Digi
Product Line Connect IT
Product Model IT16-1002
Product Name Connect IT 16, Console Access Server with 16 Serial Ports
Product Type Device Server
Technical Information:
Device TypeConsole Server
Memory:
Standard Memory1.95 GB
Media & Performance:
Media Type SupportedOptical Fiber
Twisted Pair
I/O Expansions:
Number of Total Expansion Slots2
Network & Communication:
Ethernet Technology10 Gigabit Ethernet
Network Standard10/100/1000Base-T
10GBase-X
Interfaces/Ports:
Network (RJ-45)Yes
USBYes
Serial PortYes
PoE (RJ-45) PortYes
Number of Network (RJ-45) Ports2
Number of USB Ports2
Number of Serial Ports16
Power Description:
Input Voltage230 V AC
Physical Characteristics:
Product ColorBlack
Height1.7"
Width11.8"
Depth17.5"
Weight (Approximate)11.24 lb
Miscellaneous:
Package Contents
  • Connect IT 16, Console Access Server with 16 Serial Ports
  • 2 meter Ethernet Cable
  • D89 to RJ45 Console Adapter
Additional Information
  • Cellular Network: Digi CORE™ LTE modems Support Multiple Categories; Multiple Regions
  • Remote Managerment: Digi Remote Manager
  • Required Accessory Kits: 1 x Power Supply Kit (ITPS-PSIK or ITPS-PSEK)
  • Optional Accessory Kits: Digi CORE LTE Modems
  • SD 1 x SD/SDHC/SDXC Socket
  • Power Consumption: 30.5W
Country of OriginTaiwan
Warranty:
Limited Warranty5 Year
