APC SERVICE BYPASS PDU, 120V 15AMP W/ (8) NEMA 5-15R

APC SERVICE BYPASS PDU, 120V 15AMP W/ (8) NEMA 5-15R

Overview

Extremely reliable service bypass panels designed for APC InfraStruXure® Type A, Smart-UPS, and Symmetra UPS products.

Tech Specs

Product Information

Manufacturer
Schneider Electric SA
Manufacturer Part Number
SBP1500RM
Manufacturer Website Address
http://www.schneider-electric.com
Brand Name
APC by Schneider Electric
Product Model
SBP1500RM
Product Name
8-Outlets 1.5kVA PDU
Product Type
PDU

Technical Information

Plug/Connector Type
NEMA 5-15P
Receptacle Type
NEMA 5-15R
Receptacle Detail
8 x NEMA 5-15R
Protection Type
Overload Protection

Power Description

Input Voltage
120 V
Output Voltage
120 V AC
Power Rating (VA)
1500 VA

Physical Characteristics

Mount Type
Rack-mountable
Rack Height
2U
Number of Cord/Cable
1
Cord Length
8 ft
Height
3.5"
Width
17"
Depth
3"
Weight (Approximate)
6.50 lb

Miscellaneous

Package Contents
  • 8-Outlets 1.5kVA PDU
  • Rack mounting brackets
  • User manual
  • Certifications & Standards
    TÜV
    REACH free of SVHC
    Yes
    Toxic Heavy Metal Free
    Yes
    Mercury Free
    Yes
    RoHS Exemption Information
    https://download.schneider-electric.com/files?p_enDocType=Declaration+of+Conformity+%28Sustainability%29&p_Doc_Ref=SBP1500RM_ROHS_DECLARATION&p_FileName=SBP1500RMKIT_ROHS_DECLARATION_US.pdf
    REACH Declaration URL
    https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=66016910&lang=en-us
    EU RoHS Declaration URL
    https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=66016910&lang=en-us
    Environmentally Friendly
    Yes
    Environmental Certification
    RoHS
    Environmental Compliance
    Restriction of Hazardous Substances (RoHS)

    Warranty

    Limited Warranty
    2 Year
    Additional Warranty Information
    2 years repair or replace

    Files

    Files:
    Manufacturer-Brochure
